Automatic Rotary trigger pump spray capper/ Trigger sprayer pump rotary capper with orienting device

The Automatic Rotary trigger pump spray capper/ Trigger sprayer pump rotary capper with orienting device features a stainless steel 304 body constructed to GMP standards, employing PLC control and variable frequency stepless speed regulation for the main motor drive, with intelligent electronic torque control. The upper lid section utilizes a stepped lifting belt system for efficient, low-noise lid deployment, incorporating automated lid handling functions including automatic lid positioning, lifting, and repositioning. The lid rotation mechanism integrates magnetic rotating heads with torque adjustment technology to ensure high lid closure accuracy while minimizing operational noise.

Category: Rotary Type Filling Machine For Liquid/Paste, Linear Type Filling Machine, Servo Type Capping Machine, Piston Type Filling Machine, Servo Type Filling Machine, Servo Weighing Filling Machine, Flow Meter Type Filling Machine, High Speed Rotary Capping Machine, 4 Wheels Capping Machine, Pump/Trigger Cap unscrambler, Featured Products

Description

Basic information for this Automatic Rotary trigger pump spray capper/ Trigger sprayer pump rotary capper with orienting device:

1.Servo motor or mechanical cam cover with independent servo control for cap rotation torque, featuring high output torque accuracy of single-head claw head;
2. CPK>1.33, with internal sealing and screw-cap handling method utilizing vacuum suction or grab-type mechanism;
3. The equipment operates stably with a single-unit production capacity of 50–300 bpm, and the pass rate for press cover and rotary cap assembly reaches ≥99.9%.

Performance advantages for this Automatic Rotary trigger pump spray capper/ Trigger sprayer pump rotary capper with orienting device:

Working principle: Continuous rotary operation with conformal screws for rapid and flexible bottle separation. The star wheel template guides bottles into the intermediate capping station for cap installation.
Dual stations: Cap pressing station + Cap rotating station;
Claw head gripping method: vacuum suction or grasping type;
Cap rotation method: servo actuated cap rotation;
The lifting motor adopts frequency conversion or servo motor, which can be synchronously controlled with the lid opener.
Matching automatic inner sealing plunger, automatic outer sealing plunger;

Parameters for this Automatic Rotary trigger pump spray capper/ Trigger sprayer pump rotary capper with orienting device:
