Rotary Filling Machine For Bleach／Detergent/Edible Oil/Engine Oil characteristics:
Ultra-High Speed Operation
24-head rotary design achieves speeds up to 8,000 bottles/hour, bleach filling machine maximizing production throughput for large-volume demands.
Advanced Corrosion Defense
All product-contact surfaces utilize engineered polymers and stainless-steel alloys specifically selected for chlorine-based chemical resistance.
Precision Weight-Based Filling
Integrated load cell technology ensures filling accuracy within ±0.2%, eliminating product giveaway and maintaining consistent fill volumes.
Seamless Line Integration
Rotary filling machine fully compatible with FORSTEC capping, labeling, and conveying systems for complete end-to-end automation — your complete packaging solution.
Intelligent Production Control
Bleach filling machine with PLC system with 10-inch touchscreen allows recipe storage, production monitoring, and quick changeover between different container sizes.
Main technical parameters for Rotary Filling Machine For Bleach／Detergent/Edible Oil/Engine Oil:
1.Bleach Filling Machine dimension (L×W×H)：3300mm×1600mm×2200mm
2.No. of filling head ：24
3.Diameter of bottle mouth ：≥φ18mm
4.Filling range ：160ml~2000ml
5.Production capacity ：≤6500 bottles/hour (tested by water)
6.Tolerance of filling：1000ml ±3ml
7.Voltage ：220V;50HZ
8.Power ：1.5kw
9.Air consumption :：0.55 – 0.65 Mpa clean and stable compressed air
Filling Heads: 24 independent precision heads
Production Speed: Up to 8,000 bottles/hour
Filling Accuracy: ±0.2%
Filling Range: 100ml – 5,000ml
Power Requirements: 380V/50Hz
