Operational Principle for Servo Weighing Type Filling Machine:
The core mechanism of the gravity-type filling machine relies on coordinated control between weighing sensors and filling valves. During operation, materials are fed into the storage bin via the conveying system, while a weighing platform beneath the filling head continuously monitors container weight. When a container reaches the preset weight threshold, the control system automatically closes the filling valve to complete the single filling cycle. The entire process can be divided into three distinct
High-precision weighing-type filling machine, intelligently adaptable to various materials including liquids and powders, with error control within ±0.2g. Widely applied in food, chemical, and pharmaceutical industries. Selection should consider material properties and automation requirements, with regular maintenance to ensure long-term precise operation.
stages:
-Rapid filling stage: The filling valve is fully open, allowing the material to be injected into the container at a high flow rate.
-Slow feeding stage: When the weight approaches the target value, the valve opening is reduced to decrease flow rate and improve accuracy.
-Stop phase: Upon reaching the preset weight, the valve is fully closed and the container is removed from the workstation.
Important parts for Servo Weighing Type Filling Machine:
Parameters for Servo Weighing Type Filling Machine for Big Drum/Wide mouth barrel:
