Characteristics for Ketchup/Tomato Paste Piston Filling and Screw Cap Capping Machine:
Ketchup/Tomato Paste Piston Filling and Screw Cap Capping Machine is Equipped with a filling volume adjustment handle and a filling speed adjustment knob, it allows for adjustable filling volume and filling speed, ensuring high filling precision.
The Ketchup/Tomato Paste Piston Filling and Screw Cap Capping Machine (linear rotary valve structure plunger pump filling and capping integrated machine) is a fully automated plunger pump filling system utilizing 316 stainless steel screw pumps (or plunger pumps with rotary valve structures) for material handling, specifically designed for granular concentrated paste products. Capable of filling and capping glass and plastic bottles within a capacity range of 100-1000ml at speeds of 1000-3500 bottles per hour with precision accuracy ≤±1.5%, it features a quick-release disassembly mechanism for easy cleaning, PLC-controlled variable frequency speed regulation, bottle absence detection and skipping function, bottle position correction system, vacuum leak prevention device, and compatibility with CIP (Clean-In-Place) automatic cleaning systems.
Parameters for this Ketchup/Tomato Paste Piston Filling and Screw Cap Capping Machine:
Machine details for this Ketchup/Tomato Paste Piston Filling and Screw Cap Capping Machine:
Advantages for this Ketchup/Tomato Paste Piston Filling and Screw Cap Capping Machine:
We use the closed type of the material hopper which is for GMP standard.This pneumatic plunger-type quantitative filling system employs a rotary valve plunger pump as its core filling unit. The cylinder-driven piston draws material from the hopper into the feed pipe via a three-way rotary valve, then ejects it through the same valve into the container via the filling nozzle. The filling volume is precisely controlled by regulating the cylinder stroke, with volumetric measurement implemented throughout the process. Adjustment of filling volume can be achieved by modifying the cylinder stroke or using mechanical adjustment mechanisms. To accommodate viscous paste materials, the filling head incorporates a drip-proof design.
Features for this Ketchup/Tomato Paste Piston Filling and Screw Cap Capping Machine:
The system employs PLC control and variable frequency speed regulation technology, achieving high automation. Filling parameters can be adjusted via human-machine interfaces such as touchscreens. It features bottle-deficiency non-filling and automatic counting functions, enhancing production efficiency and accuracy.
The pneumatic section employs pneumatic components, featuring stable performance and low failure rates.
The entire machine is constructed from high-quality stainless steel, with material-contact surfaces made of 304 or 316L stainless steel, complying with GMP standards.
The filling nozzle is equipped with a pneumatic anti-leakage device to ensure no wire pulling or dripping during filling.
Equipped with a filling volume adjustment handle and a filling speed adjustment knob, it allows for adjustable filling volume and filling speed, ensuring high filling precision.
Layout for this Ketchup/Tomato Paste Piston Filling and Screw Cap Capping Machine:
